HPT613-C Submersible Ceramic Level Sensor
HPT613-C Submersible ceramic level sensor is a liquid level measuring instrument with high stability and precision. It adopts fully sealed 316SS stainless steel body and ceramic core body, high explosion-proof and easy to clean.
Application :
● Water level measure
● Corrosive liquid level measurement
● Level measurement in telecom base station
● Oil level measurement
Advantages
01Surge protection from lightning strikes and voltage spikes
02Ceramic pressure cell resistant to 10x burst pressure
03Rugged design: Ingress protection up to IP 68
04Lightning (Surge) Protection
05Excellent Long Term Stability
06CE/ATEX Certificate approved
Resources
Technical Data
|
Range |
0~1 M...200 M H2O optional |
|
Output |
4~20mA;0-10V/0.5-4.5V;4-20mA HART;RS485 RTU Modbus |
|
Temperature output |
4~20mA or resistance signal; Range: -10…100 degree C |
|
Accuracy |
0.1%F.S;0.15%F.S;0.25%F.S optional |
|
Working temperature |
-20°C~+80°C |
|
Temp Compensation |
0°C~70°C |
|
Power supply |
12VDC~36VDC |
|
Medium Compatible |
316L Flush diaphragm ,316 SST,Titanium Alloy |
|
Process connection |
Flange or throw-in type |
|
Zero Temp. Drift |
0.03%FS/°C（≤100kPa）; 0.02%FS/°C（>100kPa） |
|
FS Temp. Drift |
0.003%FS/°C（≤100kPa）; 0.002%FS/°C（>100kPa） |
|
Certificate |
CE,ExiaII CT6 Ga ,ATEX,RoHS |
|
Application |
Corrosive medium |
Order information
Level range : 0-0.5m , Output : 4-20mA , Power supply : 12~36VDC ,
1m directly cable : IP68
