HR262 Guided Wave Radar Level Transmitter

Guided wave radar level transmitter is 26G High Frequency radar level measurement instrument, Antenna being further optimized, fast new microprocessor could be higher-speed signals processing.

Application :

● Temperature resistance

● Pressure resistance

● Slightly corrosive liquids

● Heap material field

● Granaries

● Diesel fuel level

Advantages
01The low noise ratio, even in case of fluctuations can get better performance
02Self-contained power supply
03Fast response, suitable for noisy or adverse conditions
04An ultra-wide user defined conductivity range allows for use in different
05Audible and visible alarms activated when the probe makes
Resources

Holykell-Measuring Instrument

Technical Data

Measurement  Span

0 to 30 meters 12m/15meters (powder);18m/20m(particle)

Signal Output

4...20mA/HART (2 wires/4 wires) RS485/Modbus

Process Connection

G1-1/2'' Thread or Flanges

Medium  Temperature

-40~150℃

Process Pressure

-1Bar~40 Bar

Accuracy

±3mm

Proof Grade

IP67

Supply

DC24V or 85-265VAC

The Frequency Span

up to 26G Hz

Explosion proof grade

Exib ⅡCT6 Gb

Order information: Range:0-5m , Output:4-20mA,  Application:For Chemical liquid
